Display & Imaging
- Native Resolution: 1920×1200 (WUXGA) – Delivers crisp, high-definition images.
- Brightness: 4500 ANSI Lumens – Ensures clear visibility even in well-lit environments.
- Contrast Ratio: 3,000,000:1 – Produces deep blacks and vibrant colors for an immersive experience.
- Display Colors: 1.07 Billion Colors – Provides accurate and vivid color reproduction.
- Light Source Type: Laser Phosphor System – Offers long-lasting and consistent brightness.
- Light Source Life: Up to 20,000 hours (Normal Mode) – Minimizes maintenance and replacement costs.
- Lamp Wattage: Nichia 67W x2 – High-quality LED-based illumination.
Optical & Projection Features
- Lens: F=2, f=2.44mm – Optimized for short-throw projection.
- Projection Offset: 140% ±6% – Helps position the image at the right height.
- Throw Ratio: 0.252 – Ultra-short throw for close-range placement.
- Optical Zoom: Fixed – Maintains focus without manual zooming.
- Digital Zoom: 0.8x – 2.0x – Allows flexible image adjustments.
- Image Size: 70″ to 200″ – Suitable for a wide range of screen sizes.
- Throw Distance: 0.06m – 0.72m (100”@0.21m) – Can project large images from a very short distance.
- Keystone Correction: H: +10°/-8° , V: +/-10° – Helps align the image properly.
Performance & Audio
- Audible Noise (Normal Mode): 34dB – Runs quietly for minimal distraction.
- Audible Noise (Eco Mode): 29dB – Even quieter operation in eco mode.
- Input Lag: 16ms – Ideal for gaming and fast-motion content.
- Resolution Support: VGA (640 x 480) to 4K (3840 x 2160) – Handles a variety of input resolutions.
- HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p – Supports all major HD formats.
- Video Compatibility: NTSC, PAL, SECAM – Works with different video formats worldwide.
- Horizontal Frequency: 15K~102KHz
- Vertical Scan Rate: 23~120Hz
Connectivity
- Input Ports:
- Computer In (Shared with Component): 1
- Composite Video: 1
- S-Video: 1
- HDMI: 2 (HDMI 2.0 with HDCP 2.2)
- Audio-in (3.5mm): 1
- Audio-in (RCA R/L): 1
- 3D VESA (Sync): 1
- HDBaseT: 1
- RJ45 (LAN Control): 1
- Output Ports:
- Monitor Out: 1
- Audio Out (3.5mm): 1
- Speakers: 10W Cube x 2 – Delivers built-in audio.
- USB Type-A (Power): 1 (5V/1.5A) – Can power external devices.
- 12V Trigger (3.5mm): 1
- Control Ports:
- RS232 (DB 9-pin male): 1
- RJ45: 1
Power & Environmental Features
- Power Supply: 100-240V ± 10%, 50/60Hz (AC Input)
- Power Consumption:
- Normal Mode: 504W
- Standby Mode: <0.5W
- Operating Temperature: 0~40℃
- Net Weight: 9.9kg
- Dimensions (W x D x H) with Adjustment Foot: 492 x 387 x 157mm
User Experience & Accessories
- OSD Language Support: 23 languages, including English, French, Spanish, Thai, Korean, German, Italian, Russian, and more.
- Standard Accessories:
- Power Cord: 1
- VGA Cable: 1
- Remote Control: 1 (with Laser Pointer)
- Quick Start Guide (QSG): 1
