PeopleLink Insta VC 4K

Optical & Imaging Features:

• Sensor: 1/2.5″ CMOS, 8.51M Effective Pixels
• Scanning Mode: Progressive
• Digital Zoom: 8X
• Lens: f=2.8mm, 120° FOV (M12 Mount)
• Autofocus: Supported
• Minimum Illumination: 0.05 Lux @ (F1.8, AGC ON)
• Shutter Speed: 1/30s ~ 1/10000s
• White Balance: Auto, Indoor, Outdoor, One Push, Manual
• Backlight Compensation: Supported
• Digital Noise Reduction: 2D & 3D DNR
• Camera Bracket: Bracket with damper for stable mounting

Video Output & Compression:

• Video System (HDMI):
  1. 4K @ 30fps / 25fps
  2. 1080P @ 30fps / 25fps
  3. 1080I @ 60fps / 50fps
  4. 720P @ 60fps / 50fps
• Resolution Options: 4K, 1080P, 720P, 960x540P, 640x360P, 320x240P
• Frame Rates: 30fps, 25fps, 24fps, 20fps, 15fps, 10fps, 7.5fps, 5fps
• Compression Formats: H.265 / H.264 / MJPEG / YUY2
• USB Video Communication Protocol: UVC v1.0/v1.1

USB & System Requirements:

• Operating Systems Supported:
  1. Windows 7, 8.1, 10 or higher (1080P and under for Windows 7)
  2. macOS 10.10 or higher
  3. Google Chrome OS (Version 29.0.1547.70 or higher)
  4. Linux
• Hardware Requirements:
  1. 2.4 GHz Intel® Core 2 Duo processor or higher
  2. 2 GB RAM or more
  3. USB 2.0 port (USB 3.0 required for 4K video output)
